Astralpool CMG Motor Cooling Fan Circlip 40209 - CX, TX and FX Pumps with a CMG Motor
This is the genuine Astralpool Circlip for the CMG motor cooling fan, part number 40209. Fluidra describes it as the Circlip Suit CMG Motor, and its motor spare parts list as the Circlip for CMG Cooling Fan. It holds the CMG cooling fan 40183 on the motor shaft. The Notos fan 40285 takes a different clip, 40285C. One circlip per fan.
- Physically Stocked, unlike most "drop-shipping" websites.
- Shipped from VIC, NSW, WA, QLD
Confirmed Compatibility
Listed by motor: CMG motors, holding the CMG cooling fan 40183 (0.75 kW and 0.93 kW CMG motors).
Pumps named for the CMG fan 40183 on Fluidra's motor spare parts list:
- CX 180, CX 240, CX 280
- TX 0.75 and TX 1 HP
- FX 340 and FX 520 (see Ask First)
Not this clip: the Notos fan 40285 on the Viron pumps and the black Notos motors takes 40285C. Fluidra's lists show no separate clip for the beige Fasco fan 40256.
Ask first: the FX 340 and FX 520 (the current models have the black Notos motor, which takes the 40285 fan and clip 40285C), and the discontinued large CMG fan 40184. Send us a photo of the motor and the old clip.
Dimensions and Specifications
| Item | Detail |
|---|---|
| Part number | 40209 |
| Fluidra description | Circlip Suit CMG Motor |
| Fluidra motor spare parts list | Circlip for CMG Cooling Fan |
| Holds | CMG cooling fan 40183 on the motor shaft |
| Quantity per pump | 1 |
| Dimensions | Not published in Astralpool's parts lists. Compare with your old part, or send us a photo |
| Barcode (EAN / GTIN) | 9343609034436 |
The CMG Circlip Rule (rev. CMC-1.0)
Confirm this circlip by the motor and fan:
- CMG motor? Read the data plate. A CMG motor with the CMG cooling fan 40183 takes this circlip.
- Notos fan? Different clip. The Notos cooling fan 40285 on the Viron pumps and the black Notos motors takes 40285C.
- Check the old circlip. If it is missing, bent, stretched or was damaged getting the fan off, or the fan moves on the shaft, order a new 40209.
- Large CMG fan or anything else? Ask first. Send us a photo of the motor data plate, the fan and the old circlip.
Why the Circlip Matters
The circlip keeps the fan locked on the end of the shaft so it turns with the motor. Without it, or with a circlip that has lost its tension, the fan can work loose along the shaft and rub on the cowl, and a damaged fan moves far less air.
These pump motors are air cooled. The fan on the rear of the motor shaft draws air in through the cowl and pushes it along the motor body, and the cowl guides that air and keeps fingers and debris away from the spinning fan. Astralpool's Viron XT installation manual says the pump must have proper ventilation to prevent the motor overheating, that overheating due to lack of cooling voids the warranty, and lists poor airflow over the motor as a cause of the HI T over temperature fault. A single speed pump has no display to warn you that it is running hot.
The same manual says to check the surroundings for leaves and debris and, with the power off, to spray a surface insecticide around the control every three months, because ants and some insects are attracted to the warm, dry environment inside the enclosure.
Astralpool Motor Fan, Cowl and Clip Chart
| Motor | Cooling fan | Fan cowl | Fan clip |
|---|---|---|---|
| Viron variable speed, Notos brushless DC motor: Viron XT P320 and P520 (all series), eVo P320, eVo P600 | 40285 | 70600 | 40285C |
| Black Notos 750W, 1100W, 1500W: 71313, 71314, 71319, now SP71613, SP71614, SP71619 (CTX 280 to 500, BX 1.0 to 2.0, FX 250 to 520, XP 1.0 to 2.0) | 40285 | 40283 | 40285C |
| Notos 3 HP and Notos three-phase motors | 40275 | 40274 | None listed |
| Fasco beige 750W, 1100W, 1500W (older CTX; Astralpool's lists number the beige motors 71323, 71324, 71329) | 40256 | 40257 | None listed |
| Fasco 2400W 3 HP | 40263 (not stocked) | 40262 | None listed |
| Fasco brushless DC (BLDC) | 40269 | 40270 (not stocked) | None listed |
| 750W mini motor 71310 (CTX 180, FX 190, E-Series) | 40251 (Fluidra description, ask first) | Ask us | Ask us |
| Fasco beige 560W | 40251 | 40244 (not stocked) | None listed |
| Notos mini and Notos 560W | 40284 (not stocked) | Ask us | Ask us |
| CMG (Fluidra lists CX, FX and TX models) | 40183 small, 40184 large (discontinued) | Ask us | 40209, this part |
Part numbers and descriptions are from Astralpool's pump spare parts lists, Fluidra's electric motor spare parts list and part descriptions, and Astralpool dealer listings (40263 and the 40284 560W description). "None listed" means no separate clip appears on those lists. "Ask us" means the lists do not show the part; send us a photo of the motor data plate and the old part.
Which Part Do I Need?
| What you have | What to order |
|---|---|
| CMG fan intact, but the circlip is missing, bent or stretched | This circlip, 40209 |
| CMG fan blades broken or hub cracked | CMG Cooling Fan 40183 and this circlip |
| Notos fan 40285 clip missing (Viron, or black Notos motor) | Notos Fan Clip 40285C |
| Beige Fasco 750W, 1100W or 1500W motor | Fasco Cooling Fan 40256 |
Related CMG and Pump Motor Parts
- CMG Cooling Fan, Small - 40183
- Notos Fan Retaining Clip - 40285C
- Fasco Cooling Fan, 750W to 1500W - 40256
- Notos Cooling Fan, 750W to 1500W and Viron - 40285
- Browse the full range: Astralpool Viron Parts | Astralpool and Zodiac Pump Spare Parts
Part Numbers and Cross-References
- Astralpool part number: 40209
- Fluidra description: Circlip Suit CMG Motor
- Fluidra motor spare parts list: Circlip for CMG Cooling Fan
- Goes with: CMG cooling fan 40183 (Motor Fan 0.75 0.93kW CMG)
- Barcode (EAN / GTIN): 9343609034436
- Different clip: 40285C, circlip for the Notos cooling fan 40285
Fitting Notes
Isolate the pump at the power point or switchboard before removing the cowl. Astralpool's pump manuals say the pump must be installed and serviced by a licensed electrician in accordance with AS/NZS 3000.
- Remove the fan cowl from the rear of the motor.
- Remove the old circlip from the end of the shaft and note how it sits.
- Check the fan. If it is cracked, has broken blades or is loose on its bore, replace it with a new 40183.
- Fit the new circlip the same way the old one sat, check the fan is held firmly and turns only with the shaft, then refit the cowl.
When to Replace
Astralpool's maintenance schedules give no service interval for the circlip. Replace it when it is missing, bent, stretched or corroded, when the fan can move on the shaft, or when it was damaged getting the fan off.
Frequently Asked Questions
Which pumps does the 40209 circlip fit?
Pumps with a CMG motor and the CMG cooling fan 40183. Fluidra's motor spare parts list names the CX 180, 240 and 280, FX 340 and 520, and TX 0.75 and 1 HP for that fan. Check the motor first, because the CX pumps on Astralpool's 2017 list and the current FX pumps have other motors.
Does 40209 fit the Notos fan 40285?
No. The Notos fan on the Viron pumps and the black Notos motors takes 40285C.
Is the circlip included with the CMG fan 40183?
No. They are separate Astralpool part numbers.
Can I reuse the old circlip?
Only if it is undamaged and still holds the fan firmly, so the fan turns with the shaft and cannot move along it. Replace it if it is bent, stretched, corroded or was damaged coming off.
Is this a genuine Astralpool part?
Yes. Heater and Spa Parts is an authorised Fluidra (Astralpool and Zodiac) dealer and warranty agent, and 40209 is the genuine Astralpool part, barcode 9343609034436.
Can I fit it myself?
Isolate the pump from power first. Astralpool's pump manuals say the pump must be installed and serviced by a licensed electrician in accordance with AS/NZS 3000. As with all of our products, it must be diagnosed and fitted by a qualified and experienced person.
