Zodiac CF Series Cartridge Filter 50mm Union (Imperial) - W89060112
Genuine replacement 50mm union (Imperial version) for Zodiac CF Series cartridge filters. Two unions are used per filter.
Part Number 13 in Diagram.
- Physically Stocked, unlike most "drop-shipping" websites.
- Shipped from VIC, NSW, WA, QLD
Specifications
| Zodiac Part Number | W89060112 |
| Manufacturer Description | 50mm Union for Cartridge Filters (Imperial) |
| Size | 50mm |
| Version | Imperial |
| Diagram Reference | No. 12 (Zodiac CF) |
| Quantity Per Filter | 2 |
Fits
- Zodiac CF Series (Titan Series) cartridge filters: CF75, CF100, CF150
Check Your Union Before Ordering
Zodiac lists four CF Series unions: 40mm Imperial (W89060110), 40mm Metric (W89060111), 50mm Imperial (W89060112) and 50mm Metric (W89060113). This listing is the 50mm Imperial version. Match the part number on your existing union, or contact us with a photo.
Emaux CF Series filters list their unions under different part numbers: 89060114 (1.5 inch) and 89060115 (2.0 inch).
Safety
The filter operates under high pressure. Air that gets into the system during servicing can become pressurised and blow the lid off. Turn the pump off before loosening the lid.
Related Zodiac CF Series Parts
- Air Release Valve W89060102 (No. 1)
- Oil Pressure Gauge 50psi W06011021 (No. 2)
- Connector for Pressure Gauge/Stopper W01111048 (No. 2)
- Ring Lock W01021006 (No. 3)
- Cartridge Filter Lid W01011002 (No. 4)
- Lid O-Ring W02011034 (No. 5)
- Pressure Release Valve W89060109 (No. 10)
- 40mm Union (Imperial) W89060110 (No. 12)
- Plug W01011015 (No. 13)
- Air Vent Pipe Fastener W01011007 (No. 14)
- Replacement elements: CF75 W88270103, CF100 W88270104, CF150 W88270105 (No. 15)
