Saltmate RP30 Replacement Cell

Saltmate RP30 Replacement Cell

Genuine Saltmate RP30 replacement electrolytic cell. This is the consumable electrode assembly for the Saltmate RP30 chlorinator, rated at 45g/hr chlorine output for pools up to 180,000 litres. Replacing the cell restores full chlorine production without replacing the powerpack.

• Physically Stocked, unlike most "drop-shipping" websites.
• Shipped from VIC, NSW, WA, QLD

Specifications

• Suits: Saltmate RP30 chlorinator
• Series: Deluxe Auto-Clean (self-cleaning)
• Chlorine output: 45g/hr
• Maximum pool size: Up to 180,000 litres
• Cell type: Self-cleaning reverse-polarity solid plate
• Supplied as: Replacement electrolytic cell (electrode assembly)
• Not included: Powerpack, cell housing and lock nut

Check Before You Order

Saltmate cells have been supplied in different configurations over the years, and some are sold with the cell O-ring and lead and some without. If you need either of those as well, check with us before ordering and we will confirm exactly what is in the box for this cell.

Does Your Cell Actually Need Replacing?

Before ordering, rule out the cheaper causes of low chlorine production:

• Low salt. Below 4000 ppm the cell cannot produce properly, and will be damaged. Test first.
• Calcium build-up. White scale bridging the plates reduces output. On a self-cleaning cell this can still occur in hard water.
• Low water flow. A blocked filter or pump basket can trip the flow switch.
• Powerpack fault. If the cell is visibly good and salt is correct, the fault may be the PCB rather than the cell.

A cell at end of life typically shows worn, pitted or heavily eroded plates, or produces little chlorine even at correct salt levels with a clean cell.

The 5000 ppm Rule (rev. SALT-1.0)

Salt level is what determines how long a Saltmate cell lasts. Before you replace a cell or a powerpack, work through this:

1. Test the salt level before adjusting anything. Take a water sample to a pool shop or use a reliable salt test. Saltmate's ideal operating range is 5000-6000 ppm.
2. Never run below 4000 ppm. Running a Saltmate chlorinator with less than 4000 ppm of salt in the pool will destroy the electrolytic cell. Low salt is the single most common cause of premature cell failure and is not covered as a manufacturing fault.
3. Top up salt before increasing the output dial. If chlorine production has dropped, check salt level and cell condition first. Winding the output up on a low-salt pool accelerates cell damage rather than fixing it.
4. Re-test after heavy rain, backwashing or topping up. Dilution drops salt concentration. Re-test seasonally and after any significant water change, and do not neglect testing through winter.

Compatibility List

This part fits the following Saltmate models:

• Saltmate RP30 - 45g/hr, pools to 180,000 litres - Auto-Clean / self-cleaning range

Does NOT Fit

• Any Saltmate model other than the RP30 - cells are matched to the powerpack output rating and are not interchangeable between ratings
• The SMT Standard range - the Standard range uses a different cell
• Any non-Saltmate chlorinator - this is a genuine Saltmate cell, not a universal fit

How to Identify Your Board

1. Read the model badge on the powerpack. It must read RP30. The cell is matched to the powerpack, not to the pool.
2. Check the plate count and cell length against your old cell. Lay the old cell alongside the photos before fitting. Saltmate has supplied more than one cell body style, including horizontal variants on some units.
3. If the badge is missing or unreadable. Send us photos of the powerpack, the old cell and the housing and we will identify it for you.

SM Series vs SMT Series

Saltmate has used both an earlier SM series and a later SMT series naming across its Standard chlorinators, and you will see both written on powerpacks and in older paperwork (for example SM90 and SMT90). They are not always interchangeable. Read the badge on your own powerpack and match it exactly - if it does not read the same as the model listed above, send us a photo of the label before ordering.

Warranty

Saltmate chlorinators are covered by the manufacturer's express warranty: 2 years full warranty on the powerpack and electrolytic cell, followed by a further 3 years pro rata warranty on the electrolytic cell. Warranty is provided by Saltmate Australia Pty Ltd. Cell damage caused by running below 4000 ppm salt, incorrect installation or chemical imbalance is not a manufacturing fault.

Frequently Asked Questions

Does this fit my Saltmate RP30?
Yes, this is the genuine replacement cell for the Saltmate RP30. Confirm the model badge on your powerpack reads RP30.

Does it include the housing?
No. This is the electrolytic cell / electrode only. The clear cell housing and powerpack are separate.

How long should a cell last?
Cell life depends heavily on salt level, water balance and running hours. Running below 4000 ppm salt will dramatically shorten it. The manufacturer covers the cell for 2 years full, then 3 years pro rata.

Can I fit a higher output cell to get more chlorine?
No. The cell must match the powerpack output rating.

My cell is white and crusty - do I need a new one?
Not necessarily. That is calcium scale. Clean the cell and re-test before replacing it.

Common search terms: Saltmate RP30 cell, Saltmate RP30 replacement cell, Saltmate RP30 electrode, salt cell 45g/hr, Saltmate chlorinator cell, replacement electrolytic cell Saltmate, WWDG SpaPro.

Manufacturer Manual & Documentation

Need wiring details, operating instructions, fault codes or full specifications? See the Saltmate operating manual (covers Auto-Clean, Standard and Pool Light models) and the Saltmate specification tables.

Before ordering: confirm this part is correct for your equipment. Check the model badge on your powerpack, seek professional assistance, or contact us with photos of your existing unit, model details, serial numbers and any labels. As with all products, this must be diagnosed and fitted by a qualified and experienced person. Electrical work must be carried out by a licensed electrician.
