Saltmate RP20 Self Cleaning Chlorinator with Digital timer

Saltmate RP20 Self Cleaning Chlorinator with Digital timer

The Saltmate RP20 is a complete Australian-made saltwater chlorinator from the self-cleaning Deluxe Auto-Clean range, supplied as a full unit with powerpack, electrolytic cell and cell housing. It produces 33g/hr of chlorine and suits pools up to 120,000 litres. Saltmate Australia has manufactured saltwater chlorination equipment in Australia since 1988.

• Physically Stocked, unlike most "drop-shipping" websites.
• Shipped from VIC, NSW, WA, QLD

Specifications

• Model: Saltmate RP20
• Series: Deluxe Auto-Clean (self-cleaning)
• Chlorine output: 33g/hr
• Maximum pool size: Up to 120,000 litres
• Cell cleaning: Automatic reverse-polarity self-cleaning
• Plumbing: Suits 40mm and 50mm pressure pipe
• Power input: 240V, 50Hz
• Casing: Water-resistant, IP34 rated
• Timeclock: Digital, with battery backup
• Salt compatibility: Standard salt and mineral salt blends
• Country of manufacture: Australia

Features

• Reverse-polarity self-cleaning cell - reduces manual cell cleaning and calcium build-up
• Automatic saltwater chlorination
• Compatible with both traditional salt and mineral salt blends
• Digital timeclock with battery backup
• Adjustable chlorine control
• Chlorine output monitor
• Solid-plate electrolytic cell with high flow rate design
• Water-resistant casing, IP34 rated
• Over-salt protection and overload protection
• Resettable circuit breaker
• Cell safety gas trap
• Cell on/off control
• Flow-sensitive safety switch
• Optional pool light transformer
• Designed and manufactured in Australia

The 5000 ppm Rule (rev. SALT-1.0)

Salt level is what determines how long a Saltmate cell lasts. Before you replace a cell or a powerpack, work through this:

1. Test the salt level before adjusting anything. Take a water sample to a pool shop or use a reliable salt test. Saltmate's ideal operating range is 5000-6000 ppm.
2. Never run below 4000 ppm. Running a Saltmate chlorinator with less than 4000 ppm of salt in the pool will destroy the electrolytic cell. Low salt is the single most common cause of premature cell failure and is not covered as a manufacturing fault.
3. Top up salt before increasing the output dial. If chlorine production has dropped, check salt level and cell condition first. Winding the output up on a low-salt pool accelerates cell damage rather than fixing it.
4. Re-test after heavy rain, backwashing or topping up. Dilution drops salt concentration. Re-test seasonally and after any significant water change, and do not neglect testing through winter.

What's Included

• 1 x Saltmate RP20 powerpack with digital timeclock and battery backup
• 1 x Saltmate RP20 electrolytic cell
• 1 x clear cell housing with unions to suit 40mm / 50mm pressure pipe

Replacement Cell for This Model

The electrolytic cell is a consumable and will need replacing periodically. The replacement cell for this unit is the Saltmate RP20 Replacement Cell - search our site for "Saltmate RP20 Replacement Cell" rather than replacing the whole chlorinator.

Warranty

Saltmate chlorinators are covered by the manufacturer's express warranty: 2 years full warranty on the powerpack and electrolytic cell, followed by a further 3 years pro rata warranty on the electrolytic cell. Warranty is provided by Saltmate Australia Pty Ltd. Cell damage caused by running below 4000 ppm salt, incorrect installation or chemical imbalance is not a manufacturing fault.

Frequently Asked Questions

What size pool does the Saltmate RP20 suit?
Up to 120,000 litres, producing 33g/hr of chlorine.

Is the RP20 self-cleaning?
Yes. It uses a reverse-polarity self-cleaning cell, which reduces how often you need to manually clean calcium off the plates.

What salt level does it need?
The ideal range is 5000-6000 ppm. Never run it below 4000 ppm - doing so will destroy the electrolytic cell.

Will it work with mineral salts?
Yes. Saltmate chlorinators are compatible with both traditional pool salt and mineral salt blends.

What pipe size does it plumb into?
The cell housing suits 40mm and 50mm pressure PVC pipe.

Do I need an electrician to install it?
The chlorinator plugs into a suitable outlet, but any hard wiring or new circuit work must be done by a licensed electrician. Plumbing should be done by a competent person.

Common search terms: Saltmate RP20, Saltmate RP20 chlorinator, Saltmate RP20 complete, salt water chlorinator 33g/hr, Saltmate self cleaning chlorinator, Saltmate RP20 powerpack, Australian made salt chlorinator, WWDG SpaPro.

Manufacturer Manual & Documentation

Need wiring details, operating instructions, fault codes or full specifications? See the Saltmate operating manual (covers Auto-Clean, Standard and Pool Light models) and the Saltmate specification tables.

Before ordering: confirm this part is correct for your equipment. Check the model badge on your powerpack, seek professional assistance, or contact us with photos of your existing unit, model details, serial numbers and any labels. As with all products, this must be diagnosed and fitted by a qualified and experienced person. Electrical work must be carried out by a licensed electrician.
