Astralpool HX 70 Gas Pool & Spa Heater — aka Hurlcon — LPG (Propane)

*The HX puts out a consistent 16kW of heat, which equals a 24kW Heat Pump in cool weather!

HX 70 Gas Heaters: Limited Stock Available

The AstralPool HX 70 gas heater is no longer in production. We have limited remaining stock of both the Natural Gas (10971) and LPG (109711) versions. Spare parts should not be an issue, as most are shared with the continuing HX 120

If you are replacing an existing HX 70, we recommend purchasing while stock remains. Alternative heaters will require plumbing modifications and may also require gas supply upgrades.

The larger HX 120 will be the replacement going forward. Most spare parts shared between the HX 70 and HX 120 will continue to be available.

Order now to secure one of the last remaining HX 70 heaters.

The Astralpool HX 70 (formerly Hurlcon HX70) is an Australian-made gas heater delivering roughly 14–16 kW of output — enough to raise 1,000 L by 20°C in about 90 minutes. This listing is the LPG (Propane) model. It drops into the same footprint and plumbing as older HX 70 heaters and is ideal for spa, swim spa and small pool gas conversions.

We keep these physically in stock, unlike most drop-shipping websites.
Genuine Authorised Dealer

Fuel type: LPG (Propane)

Connected to mains gas? See the Astralpool HX 70 — Natural Gas model.

Why Buy From Us?

Authorised Fluidra (Astralpool / Zodiac) Dealer and Warranty Agent — full warranty protection
We carry more HX / WX spare parts than anyone in Australia
Real product knowledge and genuine after-sales support

Key Details

Model: HX 70 / HX70
Fuel Type: LPG (Propane)
Output: ~14–16 kW
Heat-up: 1,000 L by 20°C in ~90 min
Ignition: Electronic, no standing pilot
Install: Indoor or outdoor rated

Documentation

Manufacturer Catalogues, Diagrams & Part Numbers

Need exploded views, spare part numbers, diagrams or more information? See the manufacturer catalogues: Astralpool Catalogue 2026 | Zodiac Catalogue 2026

Hurlcon HX70 LPG, Astralpool HX 70 Propane, HX70 replacement spa heater, MiniMax replacement, gas spa heater Australia. WWDG · SpaPro

To the layperson, plumbing sizes and their names can be confusing due to the nominal sizes and naming conventions used.

This is not something we made up. Plumbers and manufacturers have used nominal (meaning ‘by name only’) sizing for decades.

Simply put, in plumbing, named sizes are often not the actual measurements of the pipe, fitting, or part. A PVC pipe called “50mm” or “2"” does not measure 50 mm anywhere. Instead, it follows nominal sizing, an internationally-standardised naming system.

Almost all fittings we use in the pool & spa industry use “pressure PVC” pipe & fittings. Do not confuse with “DWV” or other pipe & fittings and their names and sizes.

Use the Outside Diameter (OD) to check your pipe against fittings. Below is a quick reference for common spa & pool pipe sizes:

Imperial Name	Metric Name	Pipe Diameter (OD)
1/2"	15mm	~21.2–21.5 mm
3/4"	20mm	~26.6–26.9 mm
1"	25 mm	~33.4–33.7 mm
1.5"	40 mm	~48.1–48.4 mm
2"	50 mm	~60.2–60.8 mm
2.5"	65 mm	~75.2–75.5 mm

To reiterate, these are nominal sizes and are designed to fit matching fittings — not to measure what their name suggests. These are based on PVC Pressure Pipe AS/NZ 1477 Dimensions^1.

º Internal diameters vary slightly by manufacturer and class.
¹ Not all pool/spa fittings match these dimensions exactly. Some do not follow Australian or international standards. Chinese spas may use proprietary fittings.

Understanding Plumbing Sizes & Nominal Measurements

Plumbing sizes can be confusing. PVC and many other pipe systems use nominal sizes—the size is a name, not the exact measured dimension. This convention is used across most pool and spa systems and other plumbing areas so that pipes and fittings remain compatible.

Quick example: A 2" / 50 mm fitting is named for the pipe it connects to, but the pipe’s actual outside diameter (OD) is approx. 60.3 mm (typically ~60.2–60.5 mm in AS/NZ pressure pipe).

Another example: a 2” / 50mm o-ring may refer to a barrel union, etc that suits 50mm pipe. Eg: a “50mm Balboa Gasket” refers to a heater gasket that measure 74mm across, but suits a Balboa barrel union made for 50mm pipe (and the 50mm pipe does not measure 50mm either!)

Why pipe sizes don’t match the measurements

The Nominal Pipe Size (NPS) system standardises pipe dimensions so that pipes, fittings, valves, and accessories interoperate.

Plumbers work with these nominal names every day, but DIYers can be tripped up if they try to match by a tape-measure alone.

How to Measure Pipe Correctly

Pipe size is identified by:
- The pipe’s Outside Diameter (OD).
- The fitting’s Inside Diameter (ID) (socket opening).
Pipe Class / Schedule (e.g., Class 9, 12, 18 or Sch 40) relates to wall thickness and therefore the Internal Diameter (ID) and pressure rating.
The outside diameter of a fitting is not useful (wall thickness varies by manufacturer).

Important: For pool/spa work, most plumbing uses Pressure Pipe (AS/NZ standards) — not DWV. Always check OD and the pipe class against your equipment specifications.

Hose & Tube Dimensions

Common flexible hose sizes used in pool/spa systems (approximate IDs).

Imperial Name	Metric Name	Inside Diameter (ID)
3/8"	9–10 mm	~9 mm
3/4"	19 mm	~19 mm

BSP – British Standard Pipe Thread Sizes

BSP thread names are also nominal. The thread OD will not equal the nominal name.

BSP Thread Size Naming	Outside Diameter (mm / inch)	TPI
1/16" BSP	7.7 mm / 0.304"	28
1/8" BSP	9.7 mm / 0.383"	28
1/4" BSP	13.16 mm / 0.518"	19
3/8" BSP	16.66 mm / 0.656"	19
1/2" BSP / 15 mm	20.99 mm / 0.825"	14
5/8" BSP	22.99 mm / 0.902"	14
3/4" BSP / 20 mm	26.44 mm / 1.041"	14
7/8" BSP	30.20 mm / 1.189"	14
1" BSP / 25 mm	33.25 mm / 1.309"	11
1-1/4" BSP	41.91 mm / 1.650"	11
1-1/2" BSP / 40 mm	47.80 mm / 1.882"	11
2" BSP / 50 mm	59.61 mm / 2.347"	11
2-1/4" BSP	65.71 mm / 2.587"	11
2-1/2" BSP	75.18 mm / 2.960"	11
3" BSP	87.88 mm / 3.460"	11
4" BSP	113.03 mm / 4.450"	11
5" BSP	138.43 mm / 5.450"	11
6" BSP	163.83 mm / 6.450"	11
