Astralpool XF 250 Pool & Spa Pump — 1.0HP 250 LPM Flooded Suction

Astralpool XF 250 Pool & Spa Pump — 1.0HP Flooded Suction

• We keep these physically in stock, unlike most drop-shipping websites.
• Genuine Authorised Dealer

The XF 250 is the mid-size model in the AstralPool XF Series — a flooded suction pump with no hair and lint pot, designed to sit below water level. At 1.0HP and 250 LPM it is the usual choice where the XF 140 runs out of flow: larger solar arrays, longer pipe runs and heavier circulation duty.

An inbuilt non-return valve stops the impeller reverse-rotating under high pressure, which is what keeps these reliable on solar circuits where the column drains back.

Specifications

• Model: XF 250 — AstralPool code 21110
• Motor: 1.0 HP
• Input power: 1015 W
• Full load current: 5.0 A
• Supply: 240 V, single phase
• Flow rate: 250 LPM
• Energy consumption: 1313 kWh/year
• Connections: 40 mm and 50 mm barrel unions
• No hair and lint pot — flooded suction (below water level) installation only

Typical applications

• Solar pool heating on larger arrays
• Above-ground pools
• Circulation duty on gas heaters and heat pumps
• Spa jet boosting where flooded suction is available

Replacing an older Hurlcon FX pump?

The XF Series replaces the earlier Hurlcon / AstralPool FX Series. Direct swaps are FX 140 to XF 140, FX 250 to XF 250 and FX 520 to XF 520.

The FX 190 (0.75HP / 190 LPM) and FX 340 (1.5HP / 340 LPM) have been discontinued and have no direct XF equivalent. If you are replacing an FX 190, this XF 250 is the nearest current model — it is a step up in output, so check your pipework and circuit rating before ordering. Give us a call if you are not sure.

Other models in this range

• Astralpool XF 140 — 0.5HP / 140 LPM
• Astralpool XF 520 — 2.0HP / 520 LPM
• XF Series range overview and comparison

Manufacturer Catalogues, Diagrams & Part Numbers

Need exploded views, spare part numbers, product numbers, diagrams, or more product information? See the manufacturer catalogues: Astralpool Catalogue 2026 | Zodiac Catalogue 2026

Warranty: See here
