AstralPool 40MM MULTIPORT ASSEMBLY Spare Parts

40MM MULTIPORT ASSEMBLY

AstralPool 40MM MULTIPORT ASSEMBLY Spare Parts — Tap the diagram to enlarge. AstralPool catalogue page 83.

1

Astralpool / Zodiac Handle Pin Astral Multiport Valve 75911STAINLESS STEEL PIN

75911 Qty 1 $8.00

2

Astralpool Multiport Valve Handle 40mm & 50mm - 75903BLACK HANDLE

75903 Qty 1 $29.00

3

Astralpool / Zodiac Washer AstralPool Multiport Valve Handle 75904WASATER FOR HANDLE

75904 Qty 1 $5.00

4

Astralpool / Zodiac Label 40mm Multiport Valve Valve Ningbo 75922DECAL (ASTRALPOOL)

75922 Qty 1 $12.00

5

Astralpool Multiport Valve Top Cover 40mm - 75901VALVE COVER BLACK

75901 Qty 1 $61.00

6

Astralpool / Zodiac Screw Astral Multiport Valve 75915BOLT

75915 Qty 1 $5.00

7

Astralpool / Zodiac Nut M6 To Suit Astral 40mm Multiport Valve 75913NUT

75913 Qty 1 $5.00

8

Astralpool Multiport Valve Cover O-Ring 40mm - Post Sept 2009 - 75919O-RING FOR COVER

75919 Qty 1 $12.00

9

Astralpool / Zodiac Washer Cover Astral Multiport Valve Di 75918WASHER FOR COVER

75918 Qty 1 $5.00

10

Astralpool Multiport Valve Shaft O-Ring 40mm & 50mm - CA & ECA Filters - 75905O-RING

75905 Qty 1 $5.00

11

Astralpool / Zodiac Washer Spring AstralPool Multiport Valve 75907PLASTIC SPRING WASHER

75907 Qty 1 $12.00

12

Astralpool / Zodiac Metal Washer Spring Astral 50mm Multiport Valve 75928METAL SPRING WASHER

75928 Qty 1 $5.00

13

Astralpool Multiport Valve Spring - 75912SPRING

75912 Qty 1 $38.24

14

Astralpool Multiport Valve Diverter 40mm - 75902DIVERTER

75902 Qty 1 $75.00

15

Astralpool Spider Gasket 40mm Multiport Valve, 128mm 4-Spoke - Post Sept 2009 - 75916DIVERTER SEAL

75916 Qty 1 $48.00

16

Astralpool / Zodiac Plug AstralPool Multiport Valve 40 & 50mm 75908PLUG

75908 Qty 1 $8.00

17

Astralpool / Zodiac O-Ring Astral Multiport Valve Plug 75920O-RING FOR PLUG

75920 Qty 1 $5.00

18

Astralpool Multiport Valve Body 40mm - EC, ECA, CA, FG Filters - 759001.5” BLACK VALVE BODY

75900 Qty 1 $178.00

19

Astralpool Multiport Valve Sight Glass O-Ring 40mm & 50mm - Post Sept 2009 - 75917WASHER FOR OBSERVE LID

75917 Qty 1 $5.00

20

Astralpool Multiport Valve Sight Glass 40mm & 50mm - Post Sept 2009 - 75906OBSERVE LID

75906 Qty 1 $24.00

23

Astralpool / Zodiac O-Ring Astral 40mm Multiport Valve Difuser 75921WASHER FOR DIFFUSER

75921 Qty 1 $5.00

Parts not listed here are available on request. Contact shop@hasp.com.au with your pump serial number.
