Zodiac T5 DUO Spare Parts

T5 DUO
T5

Zodiac T5 DUO Spare Parts — Tap the diagram to enlarge. Zodiac catalogue page 191.

2

Zodiac T5 Upper Thrust Washer W78004T5 Thrust Washer Upper

W78004 Qty 1 $17.00

3

Zodiac T5 Duo Float Cover W78006ZT5 Float Cover

W78006Z Qty 1 $39.00

4

Zodiac T5 Float W78014T5 Float

W78014 Qty 1 $16.00

5

Zodiac T5 Duo Main Body Cover W78003ZT5 Main Body Cover

W78003Z Qty 1 $70.00

6

Zodiac Outer Extension Tube W70718T5 Outer Extension Pipe Top

W70718 Qty 1 $32.00

7

Zodiac Cup Assembly T5 T3 R3 B3 W70719Cup Assembly

W70719 Qty 1 $23.00

8

Zodiac Inner Extension Tube T3 B3 R3 W70720T5 Inner Extension Pipe

W70720 Qty 1 $5.00

9

Zodiac Duralife Diaphragm W73010Duralife Diaphragm

W73010 Qty 1 $62.00

-

Zodiac Duralife Diaphragm 12PK W73010PKDuralife Diaphragm 12PK

W73010PK Qty 1 $557.00

10

Zodiac Engine T5 T3 B3 R3 W70717Engine

W70717 Qty 1 $105.00

11

Zodiac T5 Duo Body Bumper Ass W78071ZT5 Lower Body Assembly

W78071Z Qty 1 $627.00

12

Zodiac T5 Duo Skid Plate W78038ZT5 Skid Plate

W78038Z Qty 1 $14.00

14

Zodiac T5 Duo Front Disc Grey A0214400T5 Duo front Disc (only) grey

A0214400 Qty 1 $64.00

15

Zodiac T5 Rear Disc W78011T5 Duo rear disc (only) teal

W78011 Qty 1 $64.00

16

Zodiac T5 Duo Disc Complete W70008ZT5 Disc Complete (Front, Rear and Footpads)

W70008Z Qty 1 $94.00

17

Zodiac Au Flow Valve 1PK W70281CAD Flow Valve

W70281C Qty 1 $65.00

18

Zodiac Global Quick Hose Con BL A0176700Global Quick Hose Connector ( White for old T5 / Blue for New T5)

A0176700 Qty 1 $14.00

19

Zodiac Global Hose A0164500Global Hose

A0164500 Qty 1 $39.00

-

Zodiac Hose Jumbo Global 30PK W26060Jumbo Global Hose (Pack of 30)

W26060 Qty 1 $742.00

20

Zodiac Pool Pulse W70335Pool Pulse

W70335 Qty 1 $80.00

21

Zodiac Cuff Weir Universal Eva W70263Universal Weir Cuff

W70263 Qty 1 $21.00

23

Zodiac Adj. Wheel Deflector 1PK W70730CT5 Wheel Deflector

W70730C Qty 1 $41.00

24

Zodiac T5 Lower Thrust Washer W78005T5 Thrust Washer Lower

W78005 Qty 1 $17.00

25

Zodiac Mesh Hose Protector CL 60CM W33900Hose Protector Mesh

W33900 Qty 1 $11.00

26A

Zodiac 90 Degree Flow Elbow A0219700AU 90 Degree Flow Elbow

A0219700 Qty 1 $15.00

26B

Zodiac 90 Degree Elbow 6PK A0219700PKAU 90 Degree Flow Elbow (Pack of 6)

A0219700PK Qty 1 $90.00

Parts not listed here are available on request. Contact shop@hasp.com.au with your pump serial number.
