Zodiac OT15 / OT15 TILE Spare Parts

OT15 / OT15 TILE
OT15

Zodiac OT15 / OT15 TILE Spare Parts — Tap the diagram to enlarge. Zodiac catalogue page 185.

1

Zodiac Screw 4-12 Set Of 5 R0516700SCREW 4*12 MM (SET OF 5)

R0516700 Qty 1 $4.00

2

Zodiac Floating Cable Plug R0565600FLOATING CABLE PLUG

R0565600 Qty 1 $59.00

3

Zodiac Exhaust Valve C Set Of 3 R0633300EXHAUST VALVE C (SET OF 3)

R0633300 Qty 1 $8.00

4

Zodiac Screw 4-25mm Set Of 5 R0638900SCREW 4*25 MM (SET OF 5)

R0638900 Qty 1 $4.00

5

Zodiac Motor Block Shaft Pin Ø4 (Set of 5) - FreeRider FR200/FR1000/FR2000 iQ, Duo-X DX3000/DX4000/DX4050 iQ, Tornax TX20/TX30/TX35, OT15, FX18, CX20/CX35/CX40/CX50, Astralpool QB600/QB800, QG50 - R0657900MOTOR BLOCK SHAFT PIN Ø4 (SET OF 5)

R0657900 Qty 1 $9.00

6

Zodiac Control Unit Base R0662600CONTROL UNIT BASE

R0662600 Qty 1 $14.00

7

Zodiac Control Box TX35 R0762700CONTROL BOX FLOOR AND WALL

R0762700 Qty 1 $295.00

8

Zodiac TX FX OT Filter 100 & 200 MicronFILTER 100 MICRON

R0762900 Qty 1 $113.00

9

Zodiac TX FX OT Filter 100 & 200 MicronFILTER 200 MICRON

R0763000 Qty 1 $113.00

10

Zodiac TornaX TX20 TX30 TX35 Robotic Pool Cleaner Brush R0764900BRUSH

R0764900 Qty 1 $37.00

11

Zodiac Tracks TX R0765600TRACKS

R0765600 Qty 1 $39.00

12

Zodiac Blade Kit TX 5PK R0765800BLADE KIT (SET OF 5)

R0765800 Qty 1 $24.00

13

Zodiac Internal Flow Outlet R0766100INTERNAL FLOW OUTLET

R0766100 Qty 1 $12.00

14

Zodiac Impeller TX R0766200IMPELLER

R0766200 Qty 1 $5.00

15

Zodiac Body Complete Body Ot R0766400COMPLETE BODY GREY

R0766400 Qty 1 $147.00

16

Zodiac Holder Brush Holder TX R0767000BRUSH HOLDER

R0767000 Qty 1 $28.00

17

Zodiac Ballast Smaller Set Of 2 R0767100BALLAST SMALLER (SET OF 2)

R0767100 Qty 1 $24.00

18

Zodiac Chassis Complete Chassis TX R0767400COMPLETE CHASSIS

R0767400 Qty 1 $670.00

19

Zodiac Wheel Complete Front TX 2 R0771800COMPLETE FRONT WHEELS TX (2)

R0771800 Qty 1 $47.00

20

Zodiac Wheel Complete Back TX 2 R0771900COMPLETE BACK WHEELS TX (2)

R0771900 Qty 1 $47.00

22

Zodiac Complete Gear Kit TX R0772100COMPLETE GEAR KIT

R0772100 Qty 1 $39.00

23

Zodiac Nozzle Grey Ot R0772300NOZZLE GREY OT

R0772300 Qty 1 $13.00

24

Zodiac Cover OT15 R0830900COVER OT15

R0830900 Qty 1 $99.00

-

Zodiac Brush Pva Brush TX R0774900PVA FRONT BRUSH FOR TILED POOLS

R0774900 Qty 1 $97.00

Parts not listed here are available on request. Contact shop@hasp.com.au with your pump serial number.
